Smart Wall Panel is an energy-efficient rigid foam insulation panel made through Reaction Injection Moulding (RIM) process which comprises a non combustible insulation core sandwiched between two lightweight facer boards. It is primarily used as an insulation system for external walls, columns, and beams. It can be used in new construction projects or as a retrofit solution for existing buildings.
Legal Note : The product described is protected via various intellectual property including patent/design/copyright and trademark. We, as the intellectual right holder of the technology, design and name of the product, reserve our rights to take legal action against any third party who is using, distributing, manufacturing and/or selling the product without our express permission.
| Smart Wall Panel – U Values | ||
|---|---|---|
| Smart Wall Panel Insulation Thickness (mm) | External walls with blocks (W/m2 .0C) | External Columns & Beams (W/m2 .0C) |
| 50 | 0.540 | 0.575 |
| 60 | 0.447 | 0.471 |
| 70 | 0.382 | 0.399 |
| 80 | 0.333 | 0.346 |
| 90 | 0.295 | 0.305 |
| 100 | 0.265 | 0.273 |
| SW PIR Insulation Thermal Values | ||
|---|---|---|
| Insulation Thickness (mm) |
R=m2.K w |
|
| 34 | 1.308 | |
| 44 | 1.692 | |
| 54 | 2.077 | |
| 64 | 2.462 | |
| 74 | 2.846 | |
| 84 | 3.231 | |
